HIKROBOT MV-CH1510-10FM-M72-TF 151MP 6.2fps Mono M72-Mount 10GigE TEC Port Industrial Area Scan Camera

Product details

Model Number
Model
MV-CH1510-10FM-M72-TF
Name
151MP Area Scan Camera, IMX411, black and white, M72 port, with TEC, optical port
Performance
Sensor type
CMOS, Rolling Shutter
Sensor model
IMX411
Image element size
3.76 µm × 3.76 µm
Target surface size
66.7 mm
Resolution
14208 × 10640
Maximum frame rate
6.2 fps @ 14208 × 10640
Dynamic range
78.8 dB
Signal-to-noise ratio
45 dB
Gain
0 ~ 36 dB
Exposure time
15 μs ~ 10 sec
Shutter mode
support automatic exposure, manual exposure, one-touch exposure mode, support Rolling and Global Reset mode
Black and white/color
black and white
Pixel format
Mono 8/10/10Packed/12/12Packed/16
Binning
Supports 1 × 1，2 ×2，4 × 4
Decimation
Supports 1 × 1，2 ×2，4 × 4
Reverse image
Supports horizontal reverse image output
Electrical characteristics
Data interface
10GigE
Digital I/O
12-pin P10 connector provides power and I/O interfaces: 1 optically isolated input (Line 0), 1 optically isolated
output (Line 1), 1 bi-directional configurable non-isolated I/O (Line 2), 1 RS-232
Power supply
24 VDC
Typical power consumption
11.28 W@24 VDC (non-TEC mode)
 48.96 W@24 VDC (TEC mode)
Structure
Lens interface
M72*0.75, flange back focus 19.55 mm
External dimensions
120 mm × 120 mm × 89 mm
Weight
Approx. 2.5 kg
IP rating
IP40 (with lens and cable properly installed)
Temperature
working temperature 0℃ ~ 50℃, storage temperature -30℃ ~ 70℃
Humidity
20% ~ 95%RH non-condensing
General Specifications
Software
MVS or third-party software meeting with GigE Vision Protocol
Operating system
Windows XP/7/10/11 32/64bits
Protocol/standard
GigE Vision V2.0，GenICam
Certification
CE，FCC，RoHS，KC
