HIKROBOT MV-CH120-20GC Color Global Shutter XGS12000 CMOS 9.6fps 12MP 1″ Area Scan GigE Camera for Industrial

Product details

Model Number
Model
MV-CH120-20GC
Name
12MP Area Scan Camera, GigE, XGS12000, Color, V4
Performance
Sensor Type
CMOS, global shutter
Sensor model
XGS12000
Pixel size
3.2 µm × 3.2 µm
Target surface size
1″
Resolution
4096 × 3072
Maximum frame rate
9.6 fps @4096 × 3072 Bayer RG 8
Dynamic range
66.4 dB
Signal-to-noise ratio
40 dB
Gain
0 dB ~ 18 dB
Exposure time
Ultra-small exposure mode: 52 μs ~ 161
μs Normal exposure mode: 162 μs ~ 10 sec
Exposure mode
Off/Once/Continuous exposure mode
Black & White/Color
Color
Pixel Format
Mono 8/10/12, Bayer RG 8/10/10Packed/12/12Packed, YUV422Packed, YUV422_YUYV_Packed, RGB 8, BGR 8
Binning
Supports 1 × 1, 2 × 2, 4 × 4
Downsampling
Supports 1 × 1, 2 × 2
Mirroring
Supports horizontal and vertical reverse image output
Electrical Characteristics
Data Interface
GigE
Digital I/O
6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1),
bi-directional non-isolated I/O × 1 (Line 2).
Power supply
9 VDC to 24 VDC, supports PoE
Power consumption
Typ. 2.7 W@12 VDC
Structure
Lens mount
C-Mount
Dimensions
29 mm × 29 mm × 42 mm (1.1″ × 1.1″ × 1.7″)
Weight
Approx. 100 g (0.2 lb.)
IP protection grade
IP40 (under proper lens installation and wiring)
Temperature
Working temperature: -10 °C to 50 °C (14 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
Humidity
20% to 95% RH, non-condensing
General Specifications
Software
MVS or third-party software meeting with GigE Vision Protocol
Operating System
32/64-bit Windows XP/7/10, 32/64-bit Linux and 64-bit MacOS
Protocol/Standard
GigE Vision V2.0, GenICam
Certification
CE, RoHS, KC
