Model

Model Number

MV-IDB007X-CN

Name

1.6 million C-port very small code reader

Performance

Bar code categories

1D code: Code 39, Code 93, Code 128, ITF14, ITF25, CodaBar, EAN8, EAN13, UPCA, UPCE, etc.

2D code: QR, DataMatrix, etc.

Maximum processing frame rate

60 fps

Max. reading speed

45 yards per second

Sensor type

CMOS, global Shutter

Image element size

3.45 µm × 3.45 µm

Target surface size

1/2.9”

Resolution

1408 × 1024

Exposure time

16 μs ~ 1 sec

Gain

0 ~ 15 dB

Black and white/color

Mono

Communication protocols

SmartSDK，TCP Client，Serial，FTP，HTTP，TCP Server，Profinet，MELSEC，Ethernet/IP，ModBus，UDP，Fins，SLMP

Electrical characteristics

Data interface

Fast Ethernet（100 Mbit/s）

Digital I/O

17-pin M12 interface provides power and I/O: includes 1 non-isolated input (Line 2), 1 non-isolated output (Line 3), 2
bi-directional configurable non-isolated I/O (Line 0/1), 1 RS-232 Supports device triggering via back button

Power supply

12 ~ 24 VDC

Maximum power consumption

6 W@12 VDC

Structure

Lens Interface

C-Mount

Indicator lights

Power indicator PWR, Network indicator LNK, Status indicator STS

Dimensions

29 mm × 29 mm × 42 mm

Weight

approx. 140 g

IP protection class

IP40

Temperature

Operating temperature 0 ~ 50℃, storage temperature -30 ~ 70℃

Humidity

20% ~ 95%RH non-condensing

General Specifications

Software

IDMVS

Certification

CE，FCC，RoHS，KC
