HIKROBOT MV-CH650-90YC-M58S-NN 65MP 71fps CoaXPress Color M58-Mount Global Shutter Machine Vision Camera

Product details

Model Number
Model
MV-CH650-90YC-M58S-NN
Name
65MP Area Scan Camera, CXP-12, GMAX3265, Color, M58-mount, without fan
Performance
Sensor Type
CMOS, Global Shutter
Sensor model
GMAX3265
Pixel size
3.2 µm × 3.2 µm
Target surface size
29.9 mm × 22.4 mm
Resolution
9344 × 7000
Maximum frame rate
71 fps @9344 × 7000
Dynamic range
66 dB
Signal-to-noise ratio
40 dB
Gain
1.25x
Exposure time
12 μs ~ 10 sec
Exposure mode
Off/Once/Continuous exposure mode
Black & White/Color
Black & White
Pixel Format
Mono 8/10/12
Binning
Supports 1 × 1, 2 × 2, 4 × 4
Downsampling
Supports 1 × 1, 2 × 2, 4 × 4
Mirroring
Supports horizontal and vertical reverse image output
Electrical Characteristics
Data interface
CoaXPress
Digital I/O
12-pin P10 connector provides power and I/O: 1 optocoupler isolated input (Line 0), 1 optocoupler isolated output (Line 1), 1
bidirectional configurable non isolated I/O (Line2), and 1 RS-232
Power supply
24 VDC, CXP-0 and CXP-1 interfaces support PoCXP power supply
Typical power consumption
Typ. 13.2 W@24 VDC
Structure
Lens mount
M58*0.75, optical back focal length 11.48 mm (0.5″)
Dimensions
84 mm × 84 mm × 62.5 mm (3.3″ × 3.3″ × 2.5″)
Weight
Approx. 650 g (1.4 lb.)
IP protection grade
IP40 (under proper lens installation and wiring)
Temperature
Working temperature: 0 °C to 50 °C (32 °F to 122 °F) Storage temperature: -30 °C to 70 °C (-22 °F to 158 °F)
Humidity
20% ~ 95%RH without condensation
General Specifications
Software
MVS or frame grabber software meeting with CoaXPress Protocol
Operating system
32/64-bit Windows 7/10 with 8 GB memory or above
Protocol/Standard
CoaXPress, GenlCam
Certification
CE, RoHS, KC
