HIKROBOT MV-GT1004 Four Electrical Ports 10 Gigabit Image Capture Card for Machine Vision

HIKROBOT MV-GT1004 Four Electrical Ports 10 Gigabit Image Capture Card for Machine Vision

Product details

Model Number	Model	MV-GT1004
Model Number	Name	Four electrical ports 10 Gigabit image capture card
Memory	On-board memory	2 GB DDR3-RAM
Host Interfaces	Bus Interface	PCI-E gen2 × 8
	Bus interface performance	3900 MB/s (peak transmission bandwidth), 3350 MB/s (sustained transmission bandwidth)
	Bus Indicator	1pc
Camera Interfaces	Standard	GigE Vision V2.0
	Connector	4 × RJ45
	Support camera type	Gigabit, 10GbE industrial cameras
	Number of supported cameras	Up to 4 (total bandwidth of 27 Gbps)
	Camera interface rate	10 Gbps
	Flow channel	4 pcs
	Channel indicator	4 pairs
Processing Functions	Pixel format	Mono 8/10/10p/12/12p Bayer 8/10/10p/12/12p YUV422Packed，YUV422_YUYV_Packed RGB 8，BGR 8
General purpose I/O	I/O type	8 configurable inputs/outputs, single-ended/differential compatible Line 0/1/4/5/6/7 support 3.3 ~ 12 V input, 3.3 V output Line 2/3 support 3.3 ~ 26 V input, 3.3 V output
General purpose I/O	Connector	9 pin row of pins
Electrical Characteristics	Typical power consumption	24 W
Structure	External dimensions	126.3 mm × 181 mm × 21.4 mm
	Temperature	working temperature 0 ~ 60℃, storage temperature -20 ~ 70℃
	Humidity	10% ~ 95%RH non-condensing
General Specifications	Software	MVS
	Operating Systems	Windows 7/10
	Certifications	CE，FCC，KC，RoHS
