MV-CH120-10GM, MV-CH120-10GC
|
|
|
12 million pixel network port area scan camera, IMX304, black and white/color
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Ultra-small exposure mode: 1 μs ~ 14 μs
Normal exposure mode: 15 μs ~ 10 sec
|
|
|
support automatic exposure, manual exposure, one-key exposure mode
|
|
|
two styles of black and white and color
|
|
|
|
Mono 8/10/10Packed/12/12Packed
|
|
|
Mono 8/10/12
Bayer RG 8/10/10Packed/12/12Packed
YUV422Packed，YUV422_YUYV_Packed
RGB 8，BGR 8
|
|
|
supports 1 × 1, 1 × 2, 1 × 4, 2 × 1, 2 × 2, 2 × 4, 4 × 1, 4 × 2, 4 × 4
|
|
|
1 × 1, 1 × 2, 2 × 1, 2 × 2 supported
|
|
|
support horizontal mirroring, vertical mirroring output
|
Electrical Characteristics
|
|
|
|
|
6-pin P7 connector provides power supply and I/O: 1 optocoupler isolated input (Line0), 1 optocoupler isolated output
(Line1), 1 bidirectional configurable non-isolated I/O (Line2)
|
|
|
12 VDC, support PoE power supply
|
Typical power consumption
|
|
|
|
|
|
|
|
|
|
|
|
|
|
IP30 (when the lens and cable are installed correctly)
|
|
|
working temperature 0℃~ 50℃, storage temperature -30℃~ 70℃
|
|
|
20% ~ 80%RH without condensation
|
|
|
|
MVS or 3rd party software supporting GigE Vision protocol
|
|
|
Windows XP/7/10 32/64bits, Linux 32/64bits and MacOS 64bits
|
|
|
GigE Vision V2.0, GenICam
|
|
|
|
